Product Description:
This machine is specially used for the production of T-shirt bags, using automatic punching andcuttingintegration process, to ensure stable and reliable quality.
The main motor is controlled by frequency converter, and the whole equipment is fully controlledby PLC system.
The manipulator realizes automatic clamping, the double platform realizes automatic feeding, andit is convenient to collect.
TECHNICAL PARAMETERS：
| Model | D500 | D650 |
|---|---|---|
| Lane | Double-Line | Single Line |
| Max Cutting Width | 450mm * 2 | 600mm * 1 |
| Max Making Length | 800mm | 1000mm |
| Film Thickness | 0.01-0.2mm | 0.01-0.2mm |
| Length Error | <0.5mm | <0.5mm |
| Total Power | 10KW | 6KW |
| Max Output | 200pcs/min * 1 | 200pcs/min * 2 |
| Demension | 6000*1560*1800mm | 6000*1200*1800mm |
| Weight | 2800T | 1500T |
Primary production：
